WL-8708 Universal Testing Machine Plug Voltage Drop Testing Machine TESTING FOR VOLTAGE DROP Voltage detector
The wire sequence inspecting device adopts vision technology and intelligent algorithms to determine compliance with preset standards, automatically identify the color of the harness, so as to make sure the wiring sequence is 100% correct.| Model | WL-8708 |
| Load current | 0-40A/100A, continuously adjustable |
| Voltage drop range | 0-200mV |
| Power | AC220V/50Hz (110V customizable) |
Features:
| Nominal cross section of cable mm2 | Test current (A) | Voltage drop mV |
| 0.22 | 1 | 2 |
| 0.35 | 2 | 2.5 |
| 0.5 | 5 | 3 |
| 0.75 | 10 | 6 |
| 1 | 15 | 8 |
| 1.5 | 20 | 11 |
| 2 | 21 | 14 |
| 2.5 | 30 | 16 |
| 3 | 32 | 17 |
| 4 | 35 | 18 |
| 5 | 37 | 20 |
| 6 | 40 | 20 |
| 10 | 50 | 25 |
| 16 | 60 | 15 |
| 25 | 70 | 18 |
| 35 | 80 | 20 |
| 50 | 90 | 23 |
| 70 | 100 | 25 |
